Description

Butyl rubber waterproof sealing tape is made of butyl rubber-coated aluminum film, using the latest patented technology, through a special process produced by the environment-friendly solvent-free sealing adhesive material.  It is a quick and effective method of sealing and repairing that produces lasting protection in all climates.

Product Description

BUTYL TAPE

BUTYL RUBBER ADHESIVE TAPE

Excellent water resistance

Environmentally friendly

Extremely strong viscosity



Product Advantages

ADVANTAGES

1. Thickened metal square aluminum foil surface. more than 5 times longer than ordinary aluminum foil



2. Weather fastness resistance. High & low-temperature resistance



3. Excellent chemical resistance, and corrosion resistance. good anti-aging performance



4. Excellent water resistance. Leak tightness. High bonding & tensile strength.



5. Excellent elasticity & extension performance. Strong adaptability to the shape change and crack of the interface.

Product Details

Aluminum Surface

Butyl Rubber

Isolation Film

Surface Material

Smooth Aluminum

Square Aluminum

MORE SURFACE MATERIAL

Green Aluminum Film

HDPE Film

Red Aluminum Film

Blue Aluminum Film

White Aluminum Film

Large Square Aluminum Film

Small Square Aluminum Film

Non-woven Fabric Film

Light Body Film

Technical Parameters

Thickness (mm)	0.7, 0.8, 1.0, 1.2, 1.5, 2.0, 3.0, 4.0…12mm or Customized
Width (cm)	1.5, 3, 5, 7.5, 10, 15, 20, 25… 100 or Customized
Length (m)	10, 15, 20, 25, 30 or Customized
Surface	Aluminum, Non-woven Fabric, HDPE etc
Material	Butyl



Properties	Test Result	Test Method
Specific Gravity Ib./gal (US)	15.4	ASTM D 792
Low-Temperature Flexibility	No loss of adhesion or cracking	ASTM C 765
Weight Loss after Heat Aging	0.39	ASTM C 771
Oil Migration/Plasticizer Bleed-Out	Slight wetting on top. No bleed	ASTM C 772
Softness mm penetration	9.7	ASTM C 782
Tensile Adhesive Strength lb. force	34.0 MOF: Cohesive	ASTM C 907
Yield Strength, Ib. force	8.0	ASTM C 908



Product Application

Extension Flashing

Doors & Windows

RV’s Mobile Home

Vent Pipe

Chimneys

Valley Gutters

Porches

Skylights

Application Guidance

1) Clean the surface

2) Cut the tape to the required length

3) Peel & Stick

1. Cut the length
2. Tear the back film
3. Stick & smooth down
4. Test peel strength

Packaging and Delivery
